Cases

Case of Sniper Scope Parts Processing by Dongguan Sinbo Precision In the fierce global competition of precision manufacturing, Dongguan Sinbo Precision has become the core partner of numerous high - end firearm manufacturers, thanks to its profound expertise in sniper scope parts processing. As the "eyes" enabling ultra - long - range precision shooting, the accuracy of sniper scope parts is a matter of life and death, and Sinbo Precision continuously creates benchmark solutions for the industry with ultimate craftsmanship and cutting - edge technology. Challenges and Breakthroughs: Case of Complex Scope Tube Processing A renowned North American military enterprise entrusted Sinbo Precision to produce the core component, high - precision sniper scope tubes, during the development of a new - generation tactical sniper rifle. These tubes needed to meet stringent requirements in extreme environments: maintaining structural stability in temperature ranges from -40°C to 80°C and ensuring that the internal optical lenses could achieve an aiming accuracy of 0.1MOA (minute of angle) at a distance of 100 meters. In response, Sinbo Precision formed a cross - departmental technical team. For material selection, instead of traditional stainless steel, aerospace - grade titanium alloy combined with carbon fiber composite technology was adopted, reducing the tube's weight by 30% while increasing its compressive strength to 1200MPa. During processing, a five - axis CNC machining center was used in conjunction with a laser interferometer for real - time calibration, controlling the inner wall spiral thread error within ±0.003mm. To address the issue of thermal deformation, a groundbreaking liquid nitrogen cooling cutting technology was introduced, ensuring dimensional stability even during high - speed cutting. The delivered tubes, tested by the client, showed an optical axis deviation of only 0.008mm after 1000 extreme temperature cycle tests, far exceeding international military standards. Customized Solutions: Processing of Special Reticle Parts A European brand specializing in high - end hunting equipment aimed to create unique reticles for its limited - edition sniper rifles. The client required the reticles to have self - luminous functions in low - light conditions and maintain a service life of over 10 years in high - humidity, high - salinity marine environments. Sinbo Precision started with material R&D, developing a special glass containing rare - earth elements that achieved long - lasting photoluminescence through ion implantation. In processing, nanoscale laser lithography technology was applied, reducing the reticle line width to 0.0008mm, 1/100th the diameter of a human hair. To combat marine corrosion, a magnetron sputtering coating technology was innovatively used to form a three - layer protective film on the reticle surface. After 720 hours of salt spray testing, no corrosion was detected. After assembly, this reticle helped the client's product win the "Best Innovation Design Award" at an international hunting equipment exhibition, leading to a 200% year - on - year increase in orders. Quality Control and Continuous Improvement Sinbo Precision has established a "full - process digital twin" quality control system, covering spectral analysis of raw materials, AI - powered visual inspection during processing, and 3D CT scanning of finished products, enabling real - time data traceability at every stage. The company's laboratory is equipped with top - tier equipment such as Zeiss coordinate measuring machines and atomic force microscopes, ensuring nanoscale precision in part inspection. In addition, the company collaborates with multiple universities on industry - academia - research projects, regularly transforming cutting - edge technologies into practical applications. For example, the application of MEMS (Micro - Electro - Mechanical Systems) technology in scope adjustment knob processing increased the adjustment accuracy to 0.05MOA, leading industry - wide technological upgrades. With its unwavering pursuit of quality, Sinbo Precision has served over 30 renowned military and civilian firearm brands globally, exporting products to more than 50 countries and regions, and establishing itself as an internationally recognized brand in sniper scope parts processing.

Sinbo Precision Mechanical Organizes Comprehensive Health Check-ups for All Employees In a heartfelt demonstration of its commitment to employee well - being and corporate vitality, Dongguan Sinbo Precision Mechancal Co., Ltd. recently orchestrated a comprehensive health check - up campaign for its entire workforce. This initiative is a vivid reflection of the company's "people - centric" philosophy, firmly positioning itself as a guardian of employees' health. Tailored to the diverse health needs of its employees, Sinbo meticulously designed age - specific check - up programs. For employees under 40, the examinations cover general assessments (including blood pressure, height, and weight measurements), internal medicine checks, blood glucose tests, four - item liver function evaluations, and DR chest X - rays, providing a thorough overview of young employees' basic health conditions. For those above 40, an array of more in - depth tests has been added to the list. Building on the previous items, these additional tests such as blood routine, urine routine, two tumor markers, five myocardial enzyme indicators, four renal function indices, four blood lipid profiles, and electrocardiograms are aimed at precisely detecting potential health risks, extending more meticulous health care to senior employees. During the check - up process, employees, guided by the dedicated staff, underwent various examinations in an orderly manner. Professional medical personnel conducted meticulous inspections on each employee and patiently addressed their health - related inquiries. The overwhelming positive feedback from the workforce underscores the significance of this initiative. Employees expressed that this health check - up not only made them feel the warmth and care of the company but also provided them with a clearer understanding of their own health status, enabling them to approach work and life with renewed vigor. Sinbo Precision Mechancal has long prioritized the physical and mental health of its employees. Through a series of measures, including organizing regular health check - ups and hosting health - related lectures, the company has been consistently enhancing employees' health awareness and overall well - being. Looking ahead, Sinbo will steadfastly adhere to its "people - oriented" principle, remain committed to employees' health, and strive to create an even more conducive working and living environment, forging ahead hand in hand with its employees towards a brighter future. SEO Title: Sinbo Precision Mechancal Comprehensive Health Check - ups: A Pillar of Employee Well - being Keywords: Sinbo Precision Mechancal, employee health check - ups, age - specific medical examinations, people - centric corporate philosophy, health awareness enhancement, corporate care for employees Description: Discover how Dongguan Sinbo Precision Mechancal Co., Ltd. organizes comprehensive, age - tailored health check - ups for all employees, embodying its people - centric philosophy and commitment to employee well - being. Learn about the diverse check - up items and the company's continuous efforts in promoting health.

SINBO Precision's Aluminum Microchannel Heat Sink Processing in Dongguan In the dynamic and highly competitive landscape of modern manufacturing, the demand for efficient heat dissipation solutions has become more crucial than ever. SINBO Precision Mechanical Co., Ltd, based in Dongguan, has emerged as a leading player in this field, renowned for its top-notch custom precision mechanical components. Among its diverse range of offerings, the processing of aluminum microchannel heat sinks has been a particular area of expertise, catering to the needs of various industries. The Challenge: Meeting Stringent Heat Dissipation Requirements One of SINBO Precision's clients, a prominent company in the electronics industry, was in the process of developing a new generation of high-performance electronic devices. These devices were designed to operate at high frequencies, generating a substantial amount of heat during operation. To ensure their stable and reliable performance, an advanced heat sink design was required. The challenge was twofold: first, to create an aluminum microchannel heat sink that could effectively dissipate the large amounts of heat generated; second, to achieve this while maintaining the highest standards of precision and quality, as even the slightest deviation could lead to compromised heat dissipation and device failure. SINBO Precision's Solution Material Selection SINBO Precision began by carefully selecting the material for the heat sink. After comprehensive research and analysis, they opted for high-quality 6063 T5 aluminum alloy. This material was chosen for several reasons. Firstly, aluminum is known for its excellent thermal conductivity, which is essential for efficient heat transfer. The 6063 T5 alloy, in particular, has a thermal conductivity of approximately 160 - 180 W/m.K, making it a suitable choice for heat sink applications. Secondly, aluminum is relatively soft and easy to process, which is beneficial for achieving the complex microchannel structures required. Additionally, it is cost-effective, making it an ideal material for mass production. The high purity of the 6063 T5 aluminum alloy, reaching over 98%, further enhanced its performance, ensuring reliable heat dissipation. Advanced Processing Techniques ** Extrusion The manufacturing process commenced with the extrusion of the aluminum alloy. The aluminum ingots were heated to a high temperature, typically around 520 - 540 °C. At this elevated temperature, the aluminum became malleable and was then forced through a specially designed extrusion die under high pressure. This process shaped the aluminum into a rod with the basic form of the heat sink. The extrusion process at SINBO Precision was carried out using state-of-the-art extrusion equipment, which allowed for precise control over the dimensions and quality of the extruded product. This ensured that the microchannel heat sink embryos had consistent and accurate dimensions, laying the foundation for the subsequent processing steps. Molding Once the aluminum rod was extruded, it was injected into a grooved mold. This mold was meticulously designed to create the intricate microchannel patterns that are characteristic of high-performance heat sinks. The molding process was crucial as it determined the final shape and structure of the microchannels, which play a vital role in enhancing heat transfer. By injecting the aluminum into the mold, SINBO Precision was able to achieve the desired microchannel geometry with high precision, ensuring optimal heat dissipation performance. Subsequent Processing CNC Machining: To further refine the shape and dimensions of the heat sink, SINBO Precision employed Computer Numerical Control (CNC) machining. This advanced machining technique enabled the company to create complex features with micron-level precision. The CNC machines were programmed to perform a series of operations, such as milling, turning, and drilling, to shape the heat sink according to the client's specifications. For example, the microchannels were machined to have smooth walls and precise dimensions, which improved the flow of coolant or air through them, enhancing heat transfer efficiency. Trimming, Drilling, and Tapping: After CNC machining, the heat sinks underwent trimming to remove any excess material and ensure clean edges. Drilling operations were carried out to create holes for mounting the heat sink onto the electronic device. Tapping was also performed to create internal threads, allowing for the use of screws or bolts for secure fastening. These operations were carried out with great precision to ensure that the heat sink could be easily integrated into the client's product. Polishing and Wire Drawing: To enhance the aesthetic appearance and heat transfer performance of the heat sink, polishing and wire drawing processes were applied. Polishing the surface of the heat sink made it smoother, reducing the resistance to the flow of coolant or air. Wire drawing, on the other hand, created a uniform texture on the surface, increasing the surface area available for heat transfer. These surface treatments not only improved the heat dissipation capabilities of the heat sink but also gave it a more professional and appealing look. Surface Treatment: A suitable surface treatment was then applied to the heat sink. Anodizing was chosen as the surface treatment method in this case. Anodizing involves creating a thick, protective oxide layer on the surface of the aluminum through an electrochemical process. This oxide layer not only provided excellent corrosion resistance but also enhanced the heat transfer coefficient. The anodized surface was also more durable and scratch-resistant, ensuring the long-term performance of the heat sink. Riveting Pin and Packaging: Finally, riveting pins were added to the heat sink for secure assembly. These pins provided additional strength and stability to the heat sink, ensuring that it could withstand the rigors of use. Once all the manufacturing processes were complete, the heat sinks were carefully packaged to prevent any damage during transportation. The packaging materials were chosen to provide adequate protection while also being environmentally friendly. The Results The aluminum microchannel heat sink processed by SINBO Precision successfully met the client's stringent thermal performance requirements. The innovative design and advanced processing techniques resulted in a heat sink with exceptional heat dissipation capabilities. The microchannel structure, combined with the high thermal conductivity of the 6063 T5 aluminum alloy, allowed for efficient heat transfer from the electronic device to the surrounding environment. This significantly reduced the operating temperature of the device, improving its performance, reliability, and lifespan. Moreover, SINBO Precision's commitment to quality control was evident throughout the manufacturing process. The company implemented strict inspection procedures at every stage, from material inspection to the final product inspection. This ensured that each heat sink met the highest quality standards, with no defects or deviations. The client was highly satisfied with the end product, and the collaboration between SINBO Precision and the client laid the foundation for further projects in the future. Conclusion This case study demonstrates SINBO Precision's expertise and capabilities in the processing of aluminum microchannel heat sinks. By leveraging advanced manufacturing techniques, high-quality materials, and strict quality control measures, the company was able to provide a customized solution that met the client's challenging requirements. As the demand for efficient heat dissipation solutions continues to grow in various industries, such as electronics, automotive, and energy, SINBO Precision is well-positioned to play a leading role in providing innovative and reliable heat sink solutions.

Case Study: Sinbo Precision's PEEK Material Parts Machining in Dongguan In the realm of high-performance engineering materials, PEEK (Polyether Ether Ketone) stands out for its exceptional properties— 耐高温 (high-temperature resistance), 耐腐蚀 (corrosion resistance), and 高强度 (high strength)—making it a preferred choice for critical applications in industries like medical devices, aerospace, and industrial automation. Dongguan Sinbo Precision Mechanical Co., Ltd., a leading precision manufacturing provider since 2013, has mastered the art of machining PEEK materials to meet the most demanding specifications. With a 34,000㎡ facility, over 600 skilled employees, and nearly 500 advanced imported machines, Sinbo Precision continues to deliver innovative solutions for complex PEEK part requirements. The Client Challenge: Medical-Grade PEEK Implant Components Sinbo Precision partnered with a European medical device manufacturer developing a new generation of spinal fusion implants. The client required PEEK polymer parts with tight dimensional tolerances (±0.02mm), ultra-smooth surface finishes (Ra ≤ 0.4μm), and compliance with ISO 13485 medical standards. PEEK’s high melting point (343°C) and tendency to exhibit thermal expansion during machining posed significant challenges: Heat Management: Excessive friction during cutting could cause material degradation or warping. Surface Integrity: Achieving a bio-compatible surface finish without micro-scratches or burrs. Complex Geometry: The implant design included intricate internal channels and thin-walled structures (wall thickness ≤ 1mm). Sinbo Precision’s Solution: Engineering Excellence for PEEK Machining 1. Material Handling & Pre-Processing Sinbo’s team started by sourcing medical-grade PEEK rods (ISO 10993-compliant) with uniform molecular orientation. The material was annealed in a controlled oven to relieve internal stresses, minimizing the risk of post-machining deformation. 2. Precision Machining Process Development Tooling Strategy: Diamond-coated end mills and carbide drills were selected to reduce friction and wear. For rough machining, a 4-flute carbide end mill with a 3° helix angle was used at a cutting speed of 80m/min and feed rate of 0.05mm/tooth to balance material removal and heat generation. Cooling System: A combination of compressed air and minimal quantity lubrication (MQL) was applied to cool the cutting zone, keeping temperatures below PEEK’s glass transition temperature (143°C) to prevent thermal distortion. Finishing Operations: High-speed polishing with diamond abrasives achieved the required surface roughness. For the thin-walled sections, Sinbo used a custom-built fixture with vacuum clamping to ensure stability during machining, reducing vibration and improving dimensional accuracy. 3. Quality Control & Compliance Dimensional Inspection: Coordinate Measuring Machines (CMMs) with 0.001mm precision verified critical dimensions, including the internal channels and mating surfaces. Surface Analysis: Optical profilometers measured surface roughness, while dye-penetrant testing ensured no micro-cracks or defects. Material Traceability: Every batch of PEEK was tracked from procurement to delivery, with complete documentation for ISO 13485 compliance. The Result: Medical-Grade Excellence and Operational Efficiency Sinbo Precision delivered the PEEK implant components ahead of schedule, exceeding the client’s expectations: 100% Compliance: All parts met ISO 13485 standards and passed biocompatibility tests. Dimensional Accuracy: Tolerances were consistently within ±0.015mm, surpassing the required ±0.02mm. Surface Finish: Average Ra value of 0.35μm ensured smooth integration with human tissue, reducing the risk of inflammation. The client praised Sinbo’s ability to balance technical precision with cost-effectiveness, noting a 20% reduction in machining time compared to previous suppliers. This partnership has since expanded to include PEEK components for orthopedic instruments and minimally invasive surgical tools. Why Sinbo Precision Leads in PEEK Machining Material Expertise: Deep understanding of PEEK’s thermal and mechanical properties allows optimized process parameters. Advanced Equipment: Investment in DMG MORI 五轴 CNC machines (五轴联动加工中心) and automated inspection systems ensures repeatability for complex geometries. Cross-Industry Experience: Expertise in aerospace (PEEK for aircraft interior components) and industrial automation (wear-resistant PEEK gears) complements medical device solutions.

英文版:Motor Shaft Processing Case of Dongguan Sinbo Precision Dongguan Sinbo Precision Mechanical Co., Ltd., a high - tech enterprise specializing in precision parts manufacturing, has made a remarkable mark in the industry since its establishment in 2013. The company occupies a modern factory area of 34,000 square meters and has a professional team of over 600 people. Equipped with nearly 500 imported advanced processing and testing equipments, its design and manufacturing team has accumulated more than 13 years of rich experience. Leveraging these advantages, the company is committed to providing high - quality customized precision parts for global customers. The motor shaft processing business holds a significant position among Sinbo Precision's numerous core businesses. As a crucial component of the motor system, the motor shaft shoulders the heavy responsibility of power transmission. During the operation of the motor, it has to withstand huge loads and torques. This requires that not only the connection parts at both ends of the motor shaft need to undergo strict heat treatment to ensure that the material has sufficient strength and rigidity, but also the processing dimensional accuracy must meet extremely strict standards. Its processing process covers various complex technologies such as turning, milling, drilling, and hobbing, and involves fine processing under different working conditions before and after heat treatment. In the pre - heat treatment processing stage, Sinbo Precision demonstrates outstanding technical strength. Taking the turning process as an example, the company uses high - precision lathe equipment to precisely shape the raw materials, ensuring the accuracy of the basic dimensions of the motor shaft. In the rough turning process, a 4 - axis shaft part processing solution is adopted, which significantly shortens the main processing time. At the same time, with the real - time feedback from the measuring equipment, the lathe can automatically compensate for errors, thus stably ensuring the processing accuracy. In the milling and drilling processes, advanced power tools are equipped to accurately complete keyway milling and drilling operations, laying a solid foundation for subsequent assembly and use. The post - heat treatment processing is also a key link that determines the quality of the motor shaft. For the finishing of the keyway of the drive motor shaft after heat treatment, Sinbo Precision carefully selects suitable high - hard steel processing end mills, such as the sh360 series. This series of tools is specially designed for semi - finishing and finishing of pre - hardened steel, quenched steel and other materials with a hardness of 45 - 65hrc. Its cutting edge diameter specifications are carefully designed, and it is combined with a high - strength, high - toughness substrate material and a newly developed high - hard coating, which significantly improves the tool life and achieves efficient and high - quality processing. In the post - heat turning of the outer circle, the company uses the pcbn turning tool bhc200p series. This series of tools is good at continuous to medium interrupted processing of quenched steel. With the new generation of tialsin coating, it can achieve high - precision and high - surface - quality processing effects, perfectly meeting the strict processing requirements of the outer circle of the motor shaft. Quality inspection runs through the entire process of motor shaft processing. Sinbo Precision relies on advanced laboratory professional equipment such as gear measuring centers to monitor and accurately detect various parameters of the motor shaft in real time. Taking the processing of the crucial transmission part of the drum - shaped spline as an example, the company strictly controls the processing error of the drum - shaped amount within 15 microns. This accuracy is much higher than the industry standard, effectively ensuring that the motor shaft can maintain stable performance with low noise and high transmission efficiency during high - speed operation. With its exquisite processing technology and strict quality control system, the motor shaft products produced by Sinbo Precision have won widespread acclaim in the market. The products are not only popular in the domestic market but also successfully exported to many countries and regions such as Germany, Japan, the United States, as well as East Asia and Africa, serving many customers in different fields. Its motor shaft products are widely used in key industries such as new energy vehicles, civil transportation, aviation, wind power and industrial robots, providing solid and reliable component support for the technological upgrading and development of various industries. Through continuous technological innovation and process optimization, Sinbo Precision has established a good reputation in the motor shaft processing field, becoming a trusted partner of many customers and strongly promoting the progress and development of the precision machinery processing industry.

Sinbo Precision Mechanical's Powder Metallurgy Production Breaks Through Complex Part Manufacturing Challenges​ As the manufacturing industry advances towards high precision and complexity, powder metallurgy technology has become the key to solving the challenges of complex part manufacturing with its unique advantages. Sinbo Precision Mechanical's recent successful completion of a complex part production project for high - end medical devices is a powerful testament to its strong capabilities in the field of powder metallurgy production.​ Project Background: Challenges Posed by Complex Requirements​ An international renowned medical device company was developing a new surgical instrument. The core part featured complex structures such as multi - curved surfaces, thin walls, and high - precision hole systems, and it also had to meet strict performance requirements such as high strength and biocompatibility. Traditional processing techniques were not only difficult to form the part but also had low material utilization and high costs. After comprehensive evaluation, Sinbo Precision Mechanical was awarded the project due to its rich powder metallurgy production experience and technical reserves.​ Technical Breakthrough: Innovative Processes Solve Problems​ Customized Powder Preparation​ To meet the part's biocompatibility and high - strength requirements, Sinbo Precision Mechanical used the gas atomization method to prepare medical - grade titanium alloy powder. By precisely controlling parameters such as atomization gas pressure, temperature, and metal liquid flow, the powder particle size was controlled between 15 - 45μm, ensuring a powder sphericity of over 98%. Meanwhile, the oxygen content was strictly controlled below 0.15%, laying the foundation for subsequent processes.​ Multi - process Coordinated Forming​ The combination of powder injection molding (PIM) and micro - injection molding techniques was adopted to overcome the challenges of complex structure forming. A precise combined mold was designed, and the gate position and runner design were optimized using mold flow analysis. The injection pressure was controlled at 120 - 150MPa, and the temperature was maintained at 180 - 200℃. This successfully achieved high - precision forming of the part's complex inner cavity and thin - wall structure, with a dimensional accuracy of ±0.03mm.​ Gradient Sintering Optimization​ In the vacuum sintering process, a gradient heating process was employed. The temperature was raised from room temperature to 600℃ at a rate of 5℃/min for debinding, then to 1250℃ at a rate of 3℃/min for solid - phase sintering, and finally held at 1350℃ for 2 hours for liquid - phase sintering. This process increased the part's density to 99.2% of the theoretical density, resulting in a uniform and fine internal structure with a tensile strength of 950MPa.​ Project Results: Technical Strength Gains Recognition​ After three months of research, development, and production, Sinbo Precision Mechanical successfully delivered the first batch of 1,000 parts. According to third - party testing, all parts met the design requirements, with a yield rate as high as 97%. The customer feedback indicated that the surgical instruments using these parts performed stably during actual operations, with their service life extended by 30%. This project not only solved the manufacturing problems for the customer but also enabled Sinbo Precision Mechanical to accumulate valuable experience in powder metallurgy production in the medical field, further consolidating its position in the industry.
