CNC Machining Precision Metal Parts Rapid Prototyping Industrial OEM Manufacturing

We support a full range of material options to match different working scenarios: 6061-T6 aluminum for general automation and mounting use, 7075-T6 aluminum for high load lightweight robotic parts, 5052 aluminum for corrosion resistant marine equipment, and 304 stainless steel for heavy duty industrial test systems. Every finished plate goes through 3 full inspection steps before packaging: all hole position CMM check, full plate flatness measurement, and cavity sharp edge deburr validation, to make sure your modules fit on it perfectly without any manual modification.

Specification Table

Core Machining Features (Processing Highlight Section)

1. 5-Axis Single-Clamp One-Piece Machining: The entire irregular plate is fixed on the 5-axis machine once, all outer profile cutting, hole drilling, cavity milling and chamfer processing are finished in one continuous workflow, no need to take off and re-clamp the part, no re-positioning error that breaks hole position accuracy.

2. Multi-Cavity Synchronous Milling: All independent step-down cavities are processed with synchronous path strategy, every cavity keeps identical parallelism and flatness, no depth difference, no tilt between different cavities.

3. Full Bore One-Pass Drilling & Reaming: All 25+ mounting holes are interpolated and reamed in one single pass, no step mark inside the bore, every hole keeps consistent concentricity to the plate main datum, no misalignment when inserting fasteners or positioning pins.

4. Full Feature Manual Sharp Edge Deburr: Every hole entrance, every cavity corner, every outer profile chamfer is manually deburred after CNC machining, no tiny flying burr or sharp edge left, no scratch risk for mating modules or assembly operators.

5. Low Temperature Stress Relieving: The full plate goes through vibratory stress relieving after all cutting operations, all internal machining stress is removed completely, no plate warpage or flatness drift even after months of long term use.

Product Advantages

• Zero misalignment assembly performance: All features share the same single datum, every mounting hole and cavity keeps perfect position accuracy, you can assemble your modules directly without any manual grinding or adjusting.

• Ultra high structural stability: Monolithic one-piece solid aluminum structure delivers 2x higher rigidity than assembled or welded plates, no flex or deflection even under heavy dynamic load.

• 100% interchangeability between batches: All plates are machined with the same single-clamp workflow, every part shares identical hole position, cavity depth and flatness, you can replace old plates on site without re-aligning all your modules.

• 100% custom to your drawings: We support full custom outer profile, hole layout, cavity depth, material selection and surface treatment, from 1 prototype piece to 1000+ mass production batches, fully follow your 2D/3D CAD files or original sample reference.

• Full traceable quality control: Every order comes with material test report, full hole position CMM inspection sheet, and flatness validation record, you don't need extra incoming quality check work before assembly.

FAQ

Q1: Can you manufacture this custom multi-cavity mounting plate exactly from my 2D drawings or 3D CAD files?
A1: Absolutely yes — we provide full turn-key OEM custom 5-axis CNC machining service. You only need to send us your design files, our engineering team will run free DFM review and send you formal quote quickly.

Q2: What other material options do you support besides 6061-T6 aluminum?
A2: 7075-T6 high strength aluminum, 5052 corrosion resistant aluminum are available for selection. Brass and 304 stainless steel can also be used for special working condition projects.

Q3: How do you control the dimensional accuracy of all these multi-hole multi-cavity features?
A3: We use 5-axis single-clamp machining technology to avoid repeated re-positioning error, all hole positions, cavity depth and plate flatness are 100% inspected by CMM coordinate measuring machine to confirm the assembly performance.

Q4: Do you support prototype testing and batch production for this plate?
A4: Yes, we support prototype validation, small batch trial orders and full mass production, to ensure all finished parts keep perfect interchangeability.

Q5: What surface treatments are available for this custom aluminum mounting plate?
A5: We provide clear anodizing, black hard coat anodizing, bead blasting, conversion coating and full deburr service, to improve corrosion resistance, surface hardness and overall part quality.

Q6: What's the risk of complex multi-cavity aluminum CNC machining, and how do you handle it?
A6: Thin wall between cavities and complex asymmetric profile will easily cause part vibration and deformation. We optimize the cutting feed and spindle parameters, use dedicated anti-deformation fixture and single-clamp workflow, to reduce plate deformation and keep all geometric features consistent.

Q7: What is the typical lead time for custom sample and bulk orders?
A7: Prototype sample lead time is 7~12 working days. Bulk production lead time depends on order quantity, we will confirm the exact timeline to you after sending the formal quote.
